It is used for cleaning and repairing industrial tubes, heat exchangers, condensers, boiler pipes, etc. in starch factories/sugar factories/steel factories/power plants/chemical plants, hull cleaning, concrete roughening and stripping, cleaning economizers, preheaters, primary coolers, air separation oil coolers, air preheaters, steam turbines, condensers, heating network heaters, etc. It can also pump clean water and thin oil for pipeline pressure testing.
The crankshaft drives the connecting rod to push the plunger to do reciprocating motion, and the inlet and outlet valves are closed to generate high-pressure water. The impact force of the water is greater than the adhesio between the dirt and the surface of the object, so the dirt is separated from the surface of the object, achieving the purpose of cleaning;
The high-pressure pump utilizes advanced German KAMAT technology, featuring a horizontal stainless steel pump head, a stainless steel nickel-plated alloy plunger, and forced water cooling. The pump housing is constructed of ductile iron, offering excellent heat dissipation and a hard, non-deformable texture. Splash lubrication or forced lubrication is used on the power end for smooth and reliable transmission, reduced friction, and improved lubricity. Pure high-pressure water cleaning eliminates the need for chemical agents and is pollution-free. This is a green, environmentally friendly, high-tech product promoted by the government.

Name | Details |
Model | GYB-3-50/1000 |
Rate Pressure | 1000 bar / 15000 psi |
Water flow | 50 L/min |
Plunger diameter | 24mm |
Inpurt speed | 1480 rpm |
Pump speed | 366 rpm |
Plunger stroke | 120 mm |
electric motor power | 1400 variable frequency high pressure cleaning machine |
