About of 85-500 motor version high pressure cleaner

   It is used for cleaning and repairing industrial tubes, heat exchangers, condensers, boiler pipes, etc. in starch factories/sugar factories/steel factories/power plants/chemical plants, hull cleaning, concrete roughening and stripping, cleaning economizers, preheaters, primary coolers, air separation oil coolers, air preheaters, steam turbines, condensers, heating network heaters, etc. It can also pump clean water and thin oil for pipeline pressure testing.


How is works


  The crankshaft drives the connecting rod to push the plunger to do reciprocating motion, and the inlet and outlet valves are closed to generate high-pressure water. The impact force of the water is greater than the adhesio between the dirt and the surface of the object, so the dirt is separated from the surface of the object, achieving the purpose of cleaning;


Product Advantage

  The high-pressure pump utilizes advanced German KAMAT technology, featuring a horizontal stainless steel pump head, a stainless steel nickel-plated alloy plunger, and forced water cooling. The pump housing is constructed of ductile iron, offering excellent heat dissipation and a hard, non-deformable texture. Splash lubrication or forced lubrication is used on the power end for smooth and reliable transmission, reduced friction, and improved lubricity. Pure high-pressure water cleaning eliminates the need for chemical agents and is pollution-free. This is a green, environmentally friendly, high-tech product promoted by the government.


Product Specifications
*Note: Technical data are subject to change without prior notice.


Name

Details

Model

GYB-3-50/1000

Rate Pressure

1000 bar / 15000 psi

Water flow

50 L/min

Plunger diameter

24mm

Inpurt speed

1480 rpm

Pump speed

366 rpm

Plunger stroke

120 mm

electric motor power

  380kw


FAQ
