About of 85-200 motor version pipe cleaning machine

  Used to dredge and remove blockages and dirt in pipelines in municipalities, residential areas, and industrial parks.


How is works


  The high-pressure pump generates a high-pressure water jet when in operation. Connect the pipe unclogging nozzle to the high-pressure pump through a high-pressure hose, and place the nozzle directly in the pipe that needs to be unclogged. When the high-pressure pump is working, the reaction force generated by the high-pressure water sprayed from the rear of the nozzle is used to push the nozzle forward quickly, and the high-pressure water jet generated by the front and rear spray holes of the nozzle is used to quickly clean the pipe. When the pipe collector pulls the nozzle back, the high-pressure water flow will flush the dirt out of the pipe bundle.


Product Advantage


  1. It cleans quickly and efficiently, effectively preventing cities from becoming seas.

  2. It thoroughly cleans oily dirt from sewer pipes, effectively addressing both the symptoms and the root cause, preventing further blockage.

  3. Operators do not need to go down the well, saving time and effort and preventing methane poisoning.


Product Specifications
*Note: Technical data are subject to change without prior notice.

model

Rated flow

Rated pressure (bar)

Drive power (kw)

M3/H

L/min

JLB-1

3

50

180

Gasoline driven 24HP

JLB-1

3

50

220

Diesel drive 26.5kw

JLB · 1B

5.1

85

200

Motor drive 30kw

JLB · 1B

5.1              85                200                Diesel drive 41kw

JLB-2

8.1

135

210

Motor drive 55kw

JLB-2             8.1             135

210

Motor drive 66kw

JLB-2

10.2

170

240

Motor drive 75kw

JLB-2             10.2             170

240             Diesel drive 84kw

JLB-2

10.2

170

280

Motor drive 90kw

JLB-2             10.2              170

280

Diesel drive 110kw

JLB-7

180

300

300

Diesel drive 200kw


FAQ
