Low-pressure water is driven by a booster pump into the three-dimensional cleaning nozzles. The pressurized water jets drive the nozzles, automatically rotating and spraying in a 360-degree spherical pattern, effectively cleaning the tank interior. Oil sludge, bacteria, sludge, dirt, and other contaminants on the tank walls are completely washed away. The water is then extracted by a sewage pump for oil-water separation and filtration. The filtered wastewater meets national discharge standards.
The crankshaft drives the connecting rod to push the plunger to do reciprocating motion, and the inlet and outlet valves are closed to generate high-pressure water. The impact force of the water is greater than the adhesio between the dirt and the surface of the object, so the dirt is separated from the surface of the object, achieving the purpose of cleaning;
1. This equipment is suitable for cleaning the interior walls of gas station storage tanks, truck-mounted tankers, large crude oil storage tanks, and similar storage tanks and boxes.
2. The fully automated tank cleaning system features fully automated cleaning, suction, separation, and water recycling.
3. Utilizing a three-dimensional rotating nozzle imported from Germany, it comprehensively cleans the tank interior, eliminating the need for manual entry.
4. Professionally engineered nozzles with precise jet coverage ensure perfect cleaning of every corner of the tank.
5. After cleaning, it effectively extracts the oil from the tank bottom and tank cleaning wastewater, performs solid-oil-water three-phase separation, performs motorized thermal regeneration, and performs precision filtration.
6. The three-dimensional rotating nozzle ensures 100% cleaning of the tank interior.
7. Pure high-pressure water cleaning eliminates the need for chemical agents and is pollution-free, making it a high-tech product promoted by environmentally friendly countries.

Name | Details |
Model | GYB-3-50/1000 |
Rate Pressure | 1000 bar / 15000 psi |
Water flow | 50 L/min |
Plunger diameter | 24mm |
Inpurt speed | 1480 rpm |
Pump speed | 366 rpm |
Plunger stroke | 120 mm |
electric motor power | 90kw |
